Name: WSRD Can-Am X3 Launch Control Module | 2017-2022 QRSX+ Clutch
Brand: Whalen's Speed R&D | Whalen Tuned
SKU: LCM STD-2SEAT
Price: 409.0 USD
Availability: InStock

WSRD Can-Am X3 Launch Control Module | 2017-2022 QRSX+ Clutch

$409.00

Application

Can-Am X3 2-Seater

Can-Am X3 4-Seater

RPM Configuration

WSRD Standard 2200 RPM Setting

WSRD Enhanced 2600 RPM Setting

Clutch Spring/System

No Thanks | I have a supportive clutching option

ADD | WSRD/KWI Pink Primary Spring (2900 RPM Engagement)

Worldwide shipping

In stock, ready to ship
Backordered, shipping soon

The WSRD Launch Control Module(LCM) is designed to allow the machine to have a controlled, consistent launch rpm by cutting ignition at the desired rpm, as well as build boost by controlling ignition retard. This unit can be added to any machine or any ones tuning and allows the user to be able to fine tune the launch rpm and how aggressive the machine will leave.

Launch Control Operation:

WSRD LCMs come standard with an operations delay
Older LCMs came configured with a three second delay between pushing the activation button and actual LCM activation
WSRD has updated this to now include a one second delay as of Feb. 1st, 2022
For proper operation please press the LCM momentary switch, wait one second and then apply gas pedal for LCM activation

The WSRD LCM has the ability to retard up to 40*. The ignition retard allows for more heat in the exhaust which assists the turbos shaft speed creating more boost.

The WSRD LCM will be sent with our standard setting of 2200 RPM cut with -30* of retard. We also offer a 2600 RPM setting that can come preloaded. This can be modified by the user. With our Max Effort LCM we can configure and assist the user with setup and if using our tune, combine both the LCM and our tuning for best results.

WSRD Standard 2200 RPM Launch Control Setting

Requires the KWI Blue Primary Spring (2500 RPM Engagement) previously found in KWI's AO Clutch Systems (PLEASE NOTE: KWI now supplies the Blue/Orange Primary Spring with all clutch systems, this does NOT support our launch control configuration.
Other vendor clutching systems will support this with similar engagement springs

WSRD Enhanced 2600 RPM Launch Control Setting

Requires the WSRD | KWI Pink Primary Spring (2900 RPM Engagement) which is listed above as a NEW available option
Other vendor clutching systems will support this with similar engagement springs

WSRD Max Effort Launch Control Setting

Please consult with John prior to purchase
Supported by KWI Tapp Clutch and STM Powersports high engagement clutch options
